4.3KW Baby Diaper Packaging Machine Diaper Bag Forming Machine Multifunction
| Place of Origin | Zhejiang |
|---|---|
| Brand Name | Xinda Pelosi |
| Certification | Machinery Test Report |
| Model Number | XP-800SBD |
| Minimum Order Quantity | 1 set |
| Price | To be negotiated |
| Packaging Details | plastic ice cube bag making machine by flying knife system packing details:stretch film & bubble film wrapping onto wooden pallet shipment will be along with spare parts, instruction manual & components' manual. |
| Delivery Time | 70 days |
| Payment Terms | T/T, Western Union, MoneyGram |
| Supply Ability | 300 Set/Sets per Year |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | Automatic Diaper Bag Forming Machine | Application | Food, Commodity |
|---|---|---|---|
| Weight | 960 KG | Production Capacity | 50bag/min, 30bag/min |
| Applicable Industries | Garment Shops, Machinery Repair Shops, Food & Beverage Factory, Restaurant, Food Shop, Food & Beverage Shops | Voltage | 220V,60HZ |
| Dimension(L*W*H) | 4200*1000*1300mm | Power Usage | 4.3KW |
| Machinery Test Report | Provided | Type | Multi-Function Packaging Machine |
| Highlight | bag forming machine multifunction,4.3kw bag forming machine,4.3kw diaper packaging machine |
||
Product Description
Automatic Diaper Bag Forming Machine,Cotton Bag Packing Machine Baby Diaper Packaging Machine
Specification :
|
Output |
Up to 200 products per minute |
|
Up to 40 m/min film speed |
|
|
Product and film characteristic may affect machine output |
|
|
Size Range |
|
|
Package cut-off length |
50-6000mm |
|
Product width |
max.215mm |
|
Product height |
max.90mm |
|
Packaging Material Reel |
|
|
Reel diameter |
≤300mm |
|
Core diameter |
≤75mm |
|
Packaging material width |
max.450mm |
|
Weight |
max. 25KG |
|
Connections |
|
|
Voltage |
220V,50HZ |
|
Power usage |
4.3KW |
|
Machine weight |
960kg |
|
Machine dimensions |
L4200mm*W1000mm*H1300mm |
|
Blade cut type |
Box motion |
|
Motor configuration |
3 servo motors and 2 variable frequency motors |
|
Optional Device |
date printer, auto feeder, gas charger, etc. |
Standard features:
3 independent motors control conveyor part, vertical sealing part and end sealing part separately
Motion controller for quick response to various commands
Accurate positioning
Temperature setting accurately by independent controller
Specially customized vertical sealing device makes PE film available
Box motion type cutter extent the height of product and helpful for the firm sealing
Food grade SUS304 contact parts
Touch screen 7”
Special features:
All control in one touch screen, user-friendly and easy operation
Empty bag prevention, no product no bag
Product cutting prevention, machine will stop once cutter cuts the product
Memory function, can store 99 groups of package parameters (product position, packing speed, bag length)
No limit for product length
Free spare parts list:
|
No. |
Item |
Qty |
|
1 |
Tool box |
1pc |
|
2 |
Horizontal seal heating bar |
1pc |
|
3 |
Vertical seal heating bar |
1pc |
|
4 |
Socket head wrench |
1set |
|
5 |
Cross screwdriver |
1pc |
|
6 |
Slot type screwdriver |
1pc |
|
7 |
Monkey wrench |
1pc |
|
8 |
Ink roll(if machine with printer) |
3pc |
|
9 |
Solid-state relay |
1pc |
|
10 |
Knife |
1pair |
|
11 |
Pusher |
5pc |
FQA :
Q1: Can you send me the installation video of this machine?
A1: Yes, please check the link for this video
Q2: Can this machine make different bag sizes?
A2: One former can make one bag width, and the bag length can be adjustable within a range. It should be ordered an extra former if you want to make the other bag width.
Q3: Does your company accept OEM?
A3: Yes, we have a professional design and technical team to accept customization.
Q4: When you can deliver the machine after the order is placed?
A4: We usually can arrange shipment after 30-40 working days, but it depends on the quantity of the products.
Q5: How about your warranty?
A5: We provide 12 months warranty, starts from the issue date of bill of lading.
Q6: What can you provide after service?
A6: We can provide machine testing video and pictures before delivery, English manual, some free spare parts, installation in clients' factory and technical training.
