Durable Bag Making Machine Parts 24V 12N 100nm Powder Clutch Brake
| Place of Origin | Zhejiang |
|---|---|
| Brand Name | Xinda Pelosi |
| Certification | None |
| Model Number | XP-PTS |
| Minimum Order Quantity | 10 set |
| Price | To be negotiated |
| Packaging Details | carton box with plastic bubble film |
| Delivery Time | 15days |
| Payment Terms | T/T, Western Union, MoneyGram |
| Supply Ability | 30000 Set/Sets per Year |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | Brake Magnetic Powder Brake Clutch | Usage | All Kind Of Industry Machinery |
|---|---|---|---|
| Magnetic Powder Weight | 10-300g | Torque | 6-400N. |
| Current | 0.8-3A | Rotation Speed | 800,1000,1400RPM |
| Voltage | 24V | Weight | 5 KG |
| Highlight | 100nm Powder Clutch Brake,24V Powder Clutch Brake |
||
Product Description
24V 12N 100nm Brake Magnetic Powder Brake Clutch For Bag Making Machine Made In China
Specification :
1.Introduction of magnetic powder brake:
Magnetic powder brake can transmit torque based on electromagnetic theory and the use of magnetic powder.It has the characteristics which magnetizing current and transmit torque has a linear relationship,It has advantages of fast response,simple structure,no pollution,no noise,no shock and vibration,energy-saving and so on.It is a versatile,superior performance of automatic control components.Magnetic brake an also be used to buffer starting,overload protection,speed control and so on.
2.Features of magnetic powder brake
1)The transmission torque has a linear relationship with the magnetizing current. The size of the torque can get controlled within large range. Under normal circumstance, the magnetizing current has a linear relationship with transitive torque within range of 5%-100% rated torque.
2)The friction part will generate heat inevitably or even destroyed when it keep continuous sliding. But this device has a complete cooling set, it will not generate a lot of heat after long time running and it has a long service life.
3.Application of magnetic powder brake
It is widely used in printing machinery, paper industry machinery, bag-making machinery, paper-making machinery , wire and cable machinery,coil machinery,wire winding machines,strapping bag machinery, textile machinery, weaving-dimensional machinery, woodworking machinery, steel extruders, CNC lathes, specialized machinery and so on.
4.Advantages of magnetic powder brake
1) High-precision torque control
2) Superior durability,long life
3) The stability of a fixed superior torque characteristics
4) Continuous operation of the use of sliding
5) Ink sleek,non-shock
6) Suitable for high-frequency operation
5.Models and specifications of magnetic powder brake
1)cellular type magnetic powder brake
|
Modle |
Torque(N.m) |
Current(A) |
Votage(V) |
Rotation speed |
Weight(kg) |
|
(RPM) |
|||||
|
FZ 6K-1 |
6 |
0.8 |
24 |
1000 |
3 |
|
FZ 12K-1 |
12 |
1 |
24 |
1000 |
4.5 |
|
FZ 25K-1 |
25 |
1.5 |
24 |
1000 |
7.5 |
|
FZ 50K-1 |
50 |
1.8 |
24 |
1000 |
12 |
|
FZ 100K-1 |
100 |
2 |
24 |
800 |
20.5 |
|
FZ 200K-1 |
200 |
2.8 |
24 |
800 |
30 |
2)Singel shaft type magnetic powder brake
|
Modle |
Torque(N.m) |
Current(A) |
Votage(V) |
Rotation speed |
Weight(kg) |
|
(RPM) |
|||||
|
FZ 6A-1 |
6 |
0.8 |
24 |
1400 |
3.5 |
|
FZ 12A-1 |
12 |
1 |
24 |
1400 |
6 |
|
FZ 25A-1 |
25 |
1.5 |
24 |
1400 |
8 |
|
FZ 50A-1 |
50 |
1.8 |
24 |
1400 |
14 |
|
FZ 100A-1 |
100 |
2 |
24 |
1000 |
28 |
|
FZ 200A-1 |
200 |
2.5 |
24 |
1000 |
50 |
|
FZ 400A-1 |
400 |
3 |
24 |
1000 |
75 |
THE HOLE BRAKE:
THE SINGLE SHAFT BRAKE:
THE DOUBLE-SHAFT CLUTCH:
THE HOLE CLUTCH:
FQA:
1. How can I get the quotation?
Please tell us the model you want,then we can quote you accordingly.
2. What’s your MOQ basis?
1 set.
3. What about the lead time for production?
Usually about 8days. It also depends on the order quantity and the type of products.
4. What is the term of delivery?
We can arrange with EXW, FOB, CIF…etc. You can choose the most convenient one or cost-effective way.
