Four Lines Heat Sealing Cold Cutting Bag Sealing And Cutting Machine 1.1kw

  • Four Lines Heat Sealing Cold Cutting Bag Sealing And Cutting Machine 1.1kw
  • Four Lines Heat Sealing Cold Cutting Bag Sealing And Cutting Machine 1.1kw
  • Four Lines Heat Sealing Cold Cutting Bag Sealing And Cutting Machine 1.1kw
Place of Origin Zhejiang
Brand Name Xinda Pelosi
Certification Machinery Test Report
Model Number XP-BS200
Minimum Order Quantity 1 set
Price To be negotiated
Packaging Details 1pc/ctn
Delivery Time 7days
Payment Terms T/T, Western Union, MoneyGram
Supply Ability 1000 Set/Sets per Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Polythene Bag Cutting And Sealing Machine Bag Type Plastic Bag
Bag Making Speed 240-450pc/min Material Plastic
Voltage 380v Dimension(L*W*H) 3.2*1.2*1.7
Power 1.1kw Warranty 1 Year
Machine Type Four Lines Heat-sealing And Cold-cutting Bag-making Machine Weight 700kg
Highlight

bag sealing and cutting machine 1.1kw

,

1.1kw plastic bag cutting and sealing machine

,

four lines bag sealing and cutting machine
Leave a Message
Product Description





Four Lines Heat-Sealing And Cold-Cutting Bag-Making ,Polythene Bag Cutting And Sealing Machine











1. Machine Introduction



It is used for producing vest bags and flat-opening bags with printing. The main motor adopts frequency

conversion motor to save more electricity and regulate speed more freely. The color code tracker with

good performance makes the sealing and cutting length more accurately and the error smaller. It adopts

advanced computer to adjust length more freely and accurately.









2. Machine Advantages



1, We use stronger steel plate for machine body, which make machine more stable

2, Computer controlling, more accurate and precise.

3, Yasawa servo motor and driver controlling, which make the cutting more accurate.

4, Electric parst is CHINT, best supplier in China.

5, Easy to operate, one woker is enough









3. Machine Parameters



Model

XDP600C

XDP700C

XDP800C

XDP900C

XDP1100C

width of sealing&cutting(mm)

500

600

700

800

1000

length of sealing&cutting(mm)

700

1200

1200

1500

1600

speed of bag-making(pc/min)

240-450

240-450

200-400

200-400

200-360

Power of motor(kw)

1.1

1.5

1.5

2

2

Weight(kg)

700

850

850

1000

1000

Outline dimension(m)

3.2*1.2*1.7

3.5*1.3*1.7

3.5*1.3*1.8

3.7*1.6*2

3.8*1.8*2.1







4.Product Application



It is used for producing vest bags and flat-opening bags with printing. The main motor adopts frequency conversion motor to save more electricity and regulate speed more freely. The color code tracker with good performance makes the sealing and cutting length more accurately and the error smaller .it adopts advanced computer to adjust length more freely and accurately.







5.Principle



Material Feeding: Poly bags are fed into the machine, either manually or automatically, to initiate the sealing and cutting process.



Sealing Mechanism: The machine utilizes a sealing mechanism, often employing heat or ultrasonic energy, to bond the edges of the poly bags together. This creates a secure seal along the desired portions of the bag.



Cutting Mechanism: Following the sealing process, the machine incorporates a cutting mechanism, such as a blade or knife, to accurately sever the sealed material, separating individual bags or removing excess material as required.



Cooling and Stacking: Once cut, the sealed poly bags may pass through a cooling station to ensure the seals are fully set and secure. Subsequently, they are stacked or collected for further processing or packaging.



Control Systems: Modern Poly Bag Cutting Sealing Machines often feature advanced control systems to regulate sealing parameters such as temperature, pressure, and duration. These systems ensure consistent and high-quality sealing results.



Safety Features: To safeguard operators during machine operation, built-in safety features such as emergency stop buttons and safety guards are typically incorporated.



Optional Features: Depending on specific requirements, some machines may offer additional features such as perforation units for creating tear-off strips, embossing units for adding patterns or markings, or stacking units for organizing finished bags.








FQA:



1,Q: Your factory is trading company or factory?
A: We are factory.


2, Q: How do your company control the machine quality?
A: First we control the raw materials quality.
Second, we control the quality of machine when we are processing.
Third, Our installment engineer will test machine.

3, Q: How about payment term, payment safety and delivery time?
A: We accept 30% deposit, balance before shipment. And Irrevocable L/C at sight.
Delivery time is 20 to 30 days. It is according to order quantity.

4,Q: What is your company after sale service?
A: Our installment engineers are available. Normally it will take about 7 to 10 days for all.
Our guarantee is one year. If there is any spare parts is broken, we can send them freely to you.
