3phase Adjustable Square Bottom Paper Bag Making Machine With Handle D Cut

Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Name | Paper Bag Machine | Machine Type | Bag Forming Machine |
---|---|---|---|
Material | Paper | Video Outgoing-inspection | Provided |
Max Speed | 30-200pcs/min | Dimension(L*W*H) | 11000*4400*1800 Mm |
Applicable Industries | Hotels, Garment Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Food & Beverage Shops, Advertising Company, Construction Works | Weight | 9000 KG |
Voltage | 3phase,380v ,12kw | Paper Thickness | 80-150g/m2 |
Highlight | D Cut Paper Bag Making Machine,3phase Paper Bag Making Machine,D Cut square bottom paper bag machine |
Adjustable Square Bottom Brown Paper Bag Production Machine With D Cut
Specification :
Model
|
XDFD-180
|
XDFD-220
|
XDFD-280
|
XDFD-330
|
XDFD-450
|
Width of Bag(mm)
|
80-180
|
80-220
|
100-280
|
150-330
|
220-450
|
Length of Bag(mm)
|
150-320
|
145-320
|
225-450
|
220-450
|
210-450
|
Width of Bag Bottom
|
50-105
|
60-120
|
60-160
|
60-160
|
80-180
|
Paper Grams(g/m2)
|
50-130
|
50-130
|
60-160
|
60-160
|
80-160
|
Inside Diameter Of Paper Core(mm)
|
76
|
76
|
76
|
76
|
76
|
Maximum Discharge Diameter(mm)
|
ɸ1200
|
ɸ1200
|
ɸ1200
|
ɸ1200
|
ɸ1200
|
Max Speed(pcs/min)
|
200
|
200
|
180
|
160
|
150
|
Total Power(kw)
|
10
|
10
|
12
|
12
|
15
|
Machine Weight (kg)
|
5000
|
5500
|
7000
|
8000
|
9000
|
Machine Size(mm)
|
9000*3000*1800
|
9000*3500*1800
|
10500*3600*1900
|
10500*3700*1900
|
10500*3800*1900
|
In general, food packaging bags will take self-supporting bags, eight-sided sealing bags, special-shaped bags.
Most of the food needs a bag with a certain amount of space, so the self-supporting bag has become the main choice for the majority of food businesses. The seller can decide the size and bag type of the bag according to the size of his product and how much he intends to put in a bag.
For example, beef jerky, dried mango, etc., have a certain volume, but the capacity of a package is not particularly large, you can choose self-contained zipper bags (zippers can be reused to protect food from moisture deterioration).
If it is some mixing bag, or the bag is also independently packaged, you can directly choose the self-supporting bag or the back seal bag. Because the seller's product can be used up by opening the bag, there is no need to choose the zipper at this time, which can better control the cost.
The product is similar to rice, dog food, so that there is a certain weight and volume in a bag, you can choose eight-sided sealing bag. There is plenty of room in the bag. Of course, some snacks and candy products in order to better attract the attention of consumers, will make bags into special-shaped bags. Not only can fit enough products, but also look very different ~
FAQ :
We work as the leading exporter of construction machinery.From numerous comparison and feedbacks from clients,our price is
competitive than the price from others.
2.Why customer prefer to do business with us directly?
1)We have our own quality control team to inspect the commodities in every part.
2)All order will send product photos for your checking before shipment, to assure the items is the same as you want.
3. How is your delivery time?
In general circumstance,we can have a immediate delivery of regular machines for our clients within 7 days,because we have a variety of resources to check machines in stock,locally and nation widely,and to receive machines in timely manner.
